Thulium Oxide Powder (Th2O3), CAS 12036-44-1
Thulium Oxide Powder (Th2O3), CAS 12036-44-1
Thulium oxide powder (Tm2O3) is a light pink powder that is commonly used as a raw material for the production of other thulium compounds, such as thulium metal, thulium fluoride, and thulium nitrate.
Thulium oxide is insoluble in water, but soluble in acids. It has a high melting point of 2,308 °C and a high thermal conductivity, making it useful in high-temperature applications. It is also used as a green phosphor in television screens, as a dopant in the production of solid-state lasers, and as a glass colorant.
Thulium oxide powder should be stored in a cool, dry place, away from heat sources and incompatible materials. Proper protective equipment, such as gloves and safety goggles, should be worn when handling this material.
Physical Properties
| Compound Formula | O3Tm2 |
|---|---|
| Molecular Weight | 385.88 |
| Appearance | White |
| Melting Point | 2,341° C (4,246° F) |
| Boiling Point | 3,945° C (7,133° F) |
| Density | 8600 kg/m3 |
| Solubility in H2O | N/A |
| Exact Mass | N/A |
| Monoisotopic Mass | 385.853144 Da |
| Charge | N/A |
Application
Thulium Oxide, also called Thulia, is the important dopant for silica-based fiber amplifiers, and also has specialized uses in ceramics, glass, phosphors, lasers. Because the wavelength of Thulium-based lasers is very efficient for superficial ablation of tissue, with minimal coagulation depth in the air or in water. This makes Thulium lasers attractive for laser-based surgery. It can also be used in portable X-ray devices that have been bombarded in a nuclear reactor as a radiation source.
Specification
| Grade | 99.9999% | 99.999% | 99.99% | 99.9% |
| CHEMICAL COMPOSITION | ||||
| Tm2O3 /TREO (% min.) | 99.9999 | 99.999 | 99.99 | 99.9 |
| TREO (% min.) | 99.9 | 99 | 99 | 99 |
| Loss On Ignition (% max.) | 0.5 | 0.5 | 1 | 1 |
| Rare Earth Impurities | ppm max. | ppm max. | ppm max. | % max. |
| Tb4O7/TREO Dy2O3/TREO Ho2O3/TREO Er2O3/TREO Yb2O3/TREO Lu2O3/TREO Y2O3/TREO |
0.1 0.1 0.1 0.5 0.5 0.5 0.1 |
1 1 1 5 5 1 1 |
10 10 10 25 25 20 10 |
0.005 0.005 0.005 0.05 0.01 0.005 0.005 |
| Non-Rare Earth Impurities | ppm max. | ppm max. | ppm max. | % max. |
| Fe2O3 SiO2 CaO CuO Cl- NiO ZnO PbO |
1 5 5 1 50 1 1 1 |
3 10 10 1 100 2 3 2 |
5 50 100 5 300 5 10 5 |
0.001 0.01 0.01 0.001 0.03 0.001 0.001 0.001 |
DATA SHEET
| MF | Tm2O3 |
| MW | 385.88 |
| Purity | 99.9999%/99.999%/99.99%/99.9% REO |
| CAS | 12036-44-1 |
| Synonyms | ThuliumOxid/Oxyde De Thulium/Oxido Del Tulio |
Packaging
We handle our products with care to ensure they remain in their original condition during storage and transportation and to preserve their quality.
