Stainless Steel Fiber Sintered Felt

High-Performance Stainless Steel Fiber Sintered Felt for Filtration and High-Temperature Applications

Stainless Steel Fiber Sintered Felt is a porous metallic filtration material manufactured by layering stainless steel fibers and sintering them under high-temperature vacuum conditions.

Compared with conventional wire mesh filters, stainless steel fiber sintered felt offers significantly higher dirt-holding capacity, finer filtration accuracy, and longer service life.

---

Product Specifications

Property	Typical Value
Material	Stainless Steel 316L
Structure	Multi-layer Sintered Metal Fiber Felt
Filtration Rating	5 μm – 70 μm
Thickness	0.3 mm – 3.0 mm
Width	Up to 1200 mm
Length	Customizable
Operating Temperature	Up to 600°C (316L)
Maximum Differential Pressure	Depending on design
Surface Type	Plain, Pleated, Composite

---

Key Features

High Filtration Efficiency

The three-dimensional fiber network provides excellent particle capture performance while maintaining low flow resistance.

Large Dirt Holding Capacity

Deep-layer filtration structure significantly increases contaminant retention compared with woven wire mesh filters.

Excellent Permeability

High porosity ensures high flow rates and low pressure drop, improving overall system efficiency.

High Temperature Resistance

Suitable for continuous operation in demanding high-temperature environments.

Corrosion Resistance

Manufactured from premium stainless steel grades to withstand aggressive chemicals and harsh process conditions.

Washable and Reusable

Can be cleaned by backflushing, ultrasonic cleaning, chemical treatment, or thermal regeneration, extending service life and reducing operating costs.

Superior Mechanical Strength

Maintains structural integrity under high-pressure and cyclic operating conditions.

---

Typical Applications

Polymer Melt Filtration

Used in polyester, nylon, polypropylene, and plastic extrusion systems to remove contaminants and gels.

Petrochemical Industry

Suitable for catalyst recovery, process fluid filtration, and high-temperature gas filtration.

Pharmaceutical Manufacturing

Provides reliable filtration performance for critical process fluids and gases.

Hydraulic and Lubrication Systems

Protects pumps, valves, and precision components from particulate contamination.

Aerospace Industry

Applied in fuel systems, hydraulic systems, and specialized filtration equipment.

Energy Industry

Used in hydrogen production, fuel cell systems, and high-temperature gas purification processes.

Environmental Protection

Suitable for dust collection, flue gas treatment, and industrial emission control systems.

---



Product Forms

Sintered Felt Sheets

Standard flat sheets for custom fabrication.

Filter Discs

Precision-cut discs for filtration assemblies.

Pleated Filter Media

Increased filtration area for high-flow applications.

Cylindrical Filter Elements

Used in industrial liquid and gas filtration systems.

Custom Components

Designed according to customer drawings and specifications.

Packaging

Standard packaging options include:

• Individual protective wrapping


• Wooden crate packaging for large orders

• Custom export packaging available

---

Storage and Handling

Store in a clean, dry environment away from corrosive substances. Handle carefully to avoid mechanical damage to the filtration surface.

---

Why Choose Our Stainless Steel Fiber Sintered Felt?

• High-quality stainless steel raw materials

• Precision-controlled fiber sintering technology

• Consistent filtration performance

• Custom dimensions and filtration ratings

• OEM and ODM manufacturing support

• Fast global delivery

• Technical consultation and engineering support

---

Request a Quote

Contact us today for pricing, technical specifications, samples, or customized Stainless Steel Fiber Sintered Felt solutions. Our engineering team can help you select the optimal filtration media for your application.
