Tantalum Wire
Tantalum Wire
Tantalum wire is a ductile and corrosion-resistant metal wire made from tantalum, a rare and hard transition metal. Tantalum wire is used in a wide range of applications, including in the electronics industry, where it is used for wiring in capacitors, in the medical industry for implants and surgical tools, and in the aerospace industry for high-temperature applications. Tantalum wire is also used in the chemical industry for its resistance to corrosion and high melting point. Tantalum wire can be produced in different diameters and can be further processed into various shapes and forms, including coils and filaments.
Tantalum Wire Properties (Theoretical)
| Molecular Weight | 180.94 |
|---|---|
| Appearance | Silvery-gray solid |
| Melting Point | 3017 °C |
| Boiling Point | 5458 °C |
| Density | 16.69 g/cm3 (20 °C) |
| Solubility in H2O | N/A |
| Crystal Phase / Structure | α: body-centered cubic (bcc) / β: tetragonal |
| Electrical Resistivity | 131 nΩ·m (20 °C) |
| Electronegativity | 1.5 Paulings |
| Heat of Fusion | 36.57 kJ/mol |
| Heat of Vaporization | 753 kJ/mol |
| Poisson's Ratio | 0.34 |
| Specific Heat | 140 J/kg·K |
| Thermal Conductivity | 57.5 W/m·K |
| Thermal Expansion | 6.3 µm/m·K |
| Vickers Hardness | 870–1200 MPa |
| Young's Modulus | 186 GPa |
| Diameter | 0.004" - 0.125" |
| Purity | 99.5% - 99.99% |
| Condition | Annealed, Unannealed |
Tantalum and tatanlum alloy Wire Specifications
- Materials: R05200, R05400, R05252 (Ta2.5W), R05255 (Ta10W), R05240 (Ta40Nb)
- Standard: ASTM B365, ASTM F560 (Medical Grade)
- Size: 0.004" - 0.125" diameter x L
- Purity: 99% - 99.999%
Tantalum Wire Mechanical Properties
| Product condition | Tensile strength (MPa) | Elongation, % |
| Annealed | 300～600 | 10～30 |
| Half annealed | >600～1000 | <5 |
| Unannealed | >1000 | <5 |
Tantalum Wire Applications
- Anode Leads for Tantalum Electrolytic Capacitors
- Made of tantalum yarn or tantalum mesh
- Making Tantalum Capacitors
- Medical tantalum wire can be used to suture nerves and tendons.
Packaging
We handle our products with care to ensure they remain in their original condition during storage and transportation and to preserve their quality.
