CG MATERIAL
Tantalum Carbide Powder (TaC), CAS No 12070-06-3
Tantalum Carbide Powder (TaC), CAS No 12070-06-3
Tantalum Carbide (TaC) powder is a refractory ceramic material with high melting and boiling points. It is a dark grey powder that is insoluble in water and is highly resistant to chemical and thermal shock. TaC is commonly used as a component in cutting tools, aerospace and defense applications due to its high hardness, excellent wear resistance and thermal conductivity. It is also used as a reinforcing phase in high-temperature composites, as well as in the production of nuclear fuels and fuel cladding due to its high melting point and resistance to radiation damage. TaC powder is available in different particle sizes and purities to suit various applications.
Tantalum Carbide Powder Properties (Theoretical)
| Compound Formula | TaC |
|---|---|
| Molecular Weight | 192.96 |
| Appearance | Brown to dark brown powder |
| Melting Point | 3,880° C (7,016° F) |
| Boiling Point | 4,780° C (8,636° F) |
| Density | 14.30 g/cm3 |
| Solubility in H2O | N/A |
| Exact Mass | N/A |
| Monoisotopic Mass | N/A |
| Charge | N/A |
| Purity | 99.0% - 99.5% |
| CAS | 12070-06-3 |
| Molecular Formula | TaC |
Tantalum Carbide Powder Chemical Analysis
|
Product |
Particle Size FSSS (μm) |
Chemical Composition (%) |
||||||||||
|
C total |
C free |
Impurity (%max) |
||||||||||
|
Nb |
Fe |
Si |
Al |
Ti |
O |
N |
Na |
Ca |
||||
|
CG-TaC-1 |
0.6-0.8 |
6.2±0.2 |
≤0.15 |
0.1 |
0.05 |
0.01 |
0.005 |
0.01 |
0.40 |
0.2 |
0.005 |
0.01 |
|
CG-TaC-2 |
0.8-1.0 |
6.2±0.2 |
≤0.15 |
0.1 |
0.05 |
0.01 |
0.005 |
0.01 |
0.30 |
0.2 |
0.005 |
0.01 |
|
CG-TaC-3 |
1.0-1.5 |
6.2±0.2 |
≤0.15 |
0.1 |
0.05 |
0.01 |
0.005 |
0.01 |
0.20 |
0.2 |
0.005 |
0.01 |
|
CG-TaC-4 |
1.5-2.0 |
6.2±0.2 |
≤0.15 |
0.1 |
0.05 |
0.01 |
0.005 |
0.01 |
0.15 |
0.2 |
0.005 |
0.01 |
Tantalum Carbide Powder Properties
Tantalum Carbide (TaC) Powder has high resistance to oxidation and high electrical conductivity.
- High purity: highest purity is 99.99%
- Small particle size: min30-50nm
- Concentrated distribution
- Typical product: D10≥1.0μm, D50 1.2~1.8μm, D90≤3.0μm
Tantalum Carbide Powder Applications
- Used in powder metallurgy
- Used as a hard coating in cutting tools, hard wear-resistant alloy tools, molds
- Used in fine ceramics
- Used in chemical vapor deposition
- Used as additives for wear and corrosion-resistant structural parts
Packaging
We handle our products with care to ensure they remain in their original condition during storage and transportation and to preserve their quality.
